High Speed Sheet Shutter “Monban” (Komatsu)

高速シートシャッター門番 3.Sheet Shutter "Monban"
高速シートシャッター門番

High Speed Sheet Shutter “Monban”

Shutter Monban is the No.1 Brand in Japan !


Komatsu Electric-Monban(TakaoEng)231123

★Takao Engineering is an agent of Shutter ‘Monban’ for sales and installation in Thailand.

★We will also welcom inquiries and contacts from other areas of south east asia , such as Vietnam, Cambodia,Malaysia, Singapore and Indonesia. We can find a best agent for you.

★The maker of HIgh speed sheet shutter “Monban” is Komatsu Electric Industry in Japan. High speed sheet shutter was invented by Mr. Akio Komatsu in 1985.

★So far, total 200,000units of Monban were shipped and installed in factories and warehouses all over the world.

★Contact:
e-mail: jsales@takaoeng.co.th

Video of  Shutter “Monban”

Video (English Subtitled Ver.)

↑This is English subtitled version. Naration is still Japanese.

Video in Thai

Video in Japanese

↑This is English subtitled version. Naration is still Japanese.

Purpose of High Speed Sheet Shutter Monban

★Shutter Monban is available as both the interior door and the exterior door for factories and warehousees.

★Shutter Monban is the best choice to be used as the entrane door for air-conditioned space in factories or warehouses.

★Shutter Monban is the best choise to be used in order to protect dusts coming inside production space or warehouse space.

★Shutter Monban is the best choise to be uesd in order to protect insects coming inside production space or warehouse space.

Features of  High Speed Sheet Shutter Monban

★It is high speed ! Indoor model of Shutter Monban can open by the speed of 3.0m/sec.

★It is auto door ! Shutter Monban is auto door. Shutter Monban can open by detecting you or your forklift with sensors

★The Sheet of Shutter Monban is half-transparent ,but very strong edough to be used for long time.

★The Sheet of Shutter Monban is the fire retardant sheet approved by JFRA (Japan Fire Retardant Association).

5 modles of High Speed Sheet Shutter Monban

Lineup of Shutter Monban is consisiting of 5 models as below.

Indoor Model(Light weight, Slim, Compact, Pipe-less)

シャッター門番(屋内モデル)

シャッター門番(屋内モデル)

●Light weight, Slim. Compact , no support pipe embeded in the sheet

●Opening Size : 600mmW~4.5mW,  600mmH~4.5mH

●Speed : Opening speed 3.2m/sec

●De-rail recovery system : In case the collision by fork lift, the de-railed sheet will stop a while and slowly going up and then automatically coming back into the rail.

●High airtight structure :It is effective for insect protection and dust protection.



Independent Standing Model(Indoor Model)

シャッター門番(自立モデル)

シャッター門番(自立モデル)

●You do not need strong wall or column to spport the shutter Monban to install.

●Opening size : 800mmW~2.5mW, 1.8mmH~2.5mH

●Speed : Opening Speed 2.6m/sec

●De-rail recovery ystem

●High air tight to protect dust or insect



Exterior Model with steel pipe

シャッター門番(屋外モデル)

シャッター門番(屋外モデル)

●Wind pressure resistance type by steel pipe embedded in the sheet

●Size :600mm~10mW, 1mH~6mH

●Speed : Opening speed 2m/sec

●For the pretction of dusts and insects



Cold Room Model

シャッター門番(冷凍冷蔵庫モデル)

シャッター門番(冷凍冷蔵庫モデル)

●available for cold room of  -25℃ to -5℃

●Size :800mmW~3.5mW, 1mH~3.5mH

●Stainless frame

●Low temperature resistance sheet

●motor and sensor is equipped with anti-sweat heater ,designed for low temperature.



Explosion proof Area Model

シャッター門番(防爆区域モデル)

シャッター門番(防爆区域モデル)

●No motor inside the shutter box, instead, shutter will be opened by air diving system.

●Explosion-proof type controller

●Size : Opening size 800mmW~4mW, 2mH~4mH

●Becase the sheet is not locked when closed, you can lift the sheet up easiily by your hand to evacuate in emrgency.

●Anti-static and non-flammable sheet

●De-rail recovery system



Shutter Monban installed in Japan

豊洲市場に採用された高速シートシャッター門番

↑Shutter Monban is working in the famous “Toyosu Fish Market” in Tokyo ,Japan.

食品工場向け

↑Indoor model installed in the food factory.

高速シートシャッター門番

↑ Exterior model

高速シートシャッター門番

屋外用の大型サイズ

↑ 10m Width Exterior Model

★Contact:
e-mail: jsales@takaoeng.co.th

 Brochure of High Speed Sheet Shutter “Monban”

★English  Brochure  →monban_general_catalog_eng201604

★Thai Brochure→Monban Catalog(Thai)

★Japanese Brochure→Monban Sougou201910(TEC)(J)

★Takao Engineering original brochure in Thai→Speed Sheet Shutter Monban(TEC)

★Takao Engineering original brochure in Japanese→シャッター門番チラシ(TEC)

(※In our original brochure open/close speed is described as 1m per second. But the current model is working as 3.2m per second!)
